RV Slide-Out Motor Repair in Fort Lauderdale
When the motor driving your slide-out room fails, you face one of two frustrating situations: the slide is stuck retracted, robbing you of your living space, or it is stuck deployed, preventing you from moving the RV entirely. Neither situation is something you want to deal with at a campsite in Hollywood or Pembroke Pines, particularly on a weekend when dealerships are closed.
Our mobile technicians carry Lippert, Schwintek, and Kwikee replacement motors on the service vehicle and can diagnose and replace most failed slide-out motors in a single visit. We also carry manual override tools for every system we service, so if your slide is stuck deployed, we retract it safely first before beginning the motor replacement.
Slide-Out Motor Systems We Service
Schwintek In-Wall Gear Motors
The Lippert Schwintek in-wall system is the most common slide-out system in travel trailers and fifth wheels manufactured after 2012. Two 12V DC gear motors - one mounted on each side of the slide room wall - drive embedded gear racks that push the room in and out. The system is compact and handles heavy room loads well, but dual-motor synchronization is critical. A single failed motor causes the slide to rack (move unevenly), which the control board detects via current imbalance and shuts down to prevent structural damage.
Symptoms of a failing Schwintek motor include: uneven slide travel (one side leading the other), grinding or clicking during operation, the slide stopping partway through travel, or the motor overload indicator appearing on the control panel. Our technicians test both motors using a current clamp meter under load - a healthy motor draws 3 to 6 amps; a failing motor draws 10 to 20 amps before shutting down.
Lippert Under-Chassis Electric Motors (Power Gear)
Lippert's under-chassis electric motor system mounts a single high-torque motor and gearbox beneath the RV floor. The motor drives a rack-and-pinion mechanism that directly pushes the slide room along floor tracks. These systems are found on a wide range of RV types and are generally robust, but the underbelly mounting exposes the motor and gearbox to road water, salt spray, and debris thrown up from Florida's highways. Motor brush wear and gearbox oil seal failure are the most common service items on these systems in South Florida.
Kwikee Cable-Drive Systems
Kwikee (manufactured by BAL) uses a centrally mounted motor that drives the slide room via a cable and rack mechanism. These systems are found on older travel trailers built in the late 1990s through mid-2000s. Kwikee systems are reliable when properly maintained but parts availability has declined as the system ages. Our team stocks the most common Kwikee motor assemblies and can advise on retrofit options if your specific motor part number is no longer available.
Wiring and Connector Diagnosis
Broward County's humidity is a major contributor to slide-out control problems that present as motor failures but are actually wiring issues. Moisture infiltrates the Molex and Deutsch connectors used throughout the Schwintek and Lippert wiring harnesses, causing intermittent contact resistance. The symptoms - a slide that sometimes works and sometimes does not, or a slide that starts moving then stops - are indistinguishable from a failing motor until the wiring is tested.
Our technicians probe the motor connectors with a digital multimeter under load conditions. Healthy connector resistance is below 0.1 ohm; a corroded connector can show 1 to 5 ohms under load, which is enough to drop the voltage at the motor below its operating threshold. Cleaning and re-sealing the connector resolves the fault without motor replacement. We find corroded connectors responsible for roughly one in four cases that are initially reported as motor failures.
Slide-Out Motor Repair Pricing in Fort Lauderdale
| Service | Estimated Range |
|---|---|
| Motor Diagnosis | $89 - $149 |
| Schwintek Motor Replacement (single) | $350 - $600 |
| Schwintek Motor Replacement (dual) | $550 - $950 |
| Lippert Under-Chassis Motor Replacement | $395 - $750 |
| Kwikee Cable Motor Replacement | $325 - $650 |
| Wiring Diagnosis and Connector Repair | $95 - $225 |
| Emergency Manual Override | $125 - $225 |
| Travel Limit Calibration (standalone) | $75 - $125 |
| Prices shown are estimates. Final pricing provided after on-site diagnosis. Parts cost separate. | |
Motor Repair FAQ - Fort Lauderdale
A failed motor typically makes a straining or grinding sound without the slide moving, trips the overload protector after a partial travel attempt, or shows zero movement despite an audible relay click. A failed control board often causes total silence - no relay click, no motor sound, no slide movement of any kind. Erratic behavior (sometimes works, sometimes does not) usually points to a connector corrosion issue or a failing control board. Our technicians test the board output signal at the motor connector before recommending motor replacement.
In moderate climates, Schwintek motors commonly last 8 to 12 years. In Florida's heat, with year-round operation and higher current draw from heat-induced resistance, 5 to 8 years is more realistic for a heavily used RV. Annual current draw testing can identify a motor that is trending toward failure before it leaves you stuck - a motor drawing more than 8 amps (versus the normal 3 to 6 amp range) is showing early failure signs.
This is the signature failure symptom of a Schwintek dual-motor system with one failed motor. The Schwintek control board drives both motors simultaneously but stops the system when it detects a current imbalance between the two sides. When one motor fails completely, the working motor pulls the slide on one side while the dead motor side stays put - causing the slide room to rack diagonally. Stop operating the slide immediately if this happens - racking beyond the normal tolerance can damage the slide room frame itself.
Our team tests both motors before recommending replacement. If the surviving motor shows a healthy current draw and the RV is relatively new (under 6 years), replacing only the failed motor is cost-effective. If the RV is older and the surviving motor tests borderline, or if the two motors have significantly different run hours, we typically recommend replacing both in a single visit - the labor for the second motor is minimal when we are already on site.
Yes. A corroded Molex connector, a chafed wire under the slide room, or a failing relay on the control board can all cause symptoms that look identical to a motor failure. This is why our technicians test voltage and ground at the motor connector before concluding the motor is at fault. A wiring diagnosis that finds a corroded connector can save you $400 or more compared to an unnecessary motor replacement.
Schwintek systems can be manually operated using a 3/8-inch drive socket on the motor shaft - the motor has a hex engagement point accessible through a small opening in the slide room panel. Operating both sides simultaneously requires two people with cordless drills. For Lippert under-chassis systems, there is a dedicated override handle stored in the RV's manual kit. Our technicians carry the correct tooling for all system types and can perform emergency retraction safely without damaging the mechanism.
A single Schwintek motor replacement takes 1.5 to 2.5 hours including disassembly, motor swap, reassembly, travel limit calibration, and full-travel test cycles. Replacing both Schwintek motors takes 2.5 to 3.5 hours. Lippert under-chassis motor replacement takes 2 to 3 hours. We bring all necessary tools and do not need any campground facilities beyond a level surface and 12V power (your RV's battery system is sufficient).
Lippert supports most of its motor line going back to the early 2000s with OEM or OEM-equivalent replacement parts. Schwintek, which Lippert acquired around 2010, is similarly well-supported. Kwikee and legacy BAL systems are the most challenging - parts availability diminishes for units built before 2005. For very old systems with unavailable OEM parts, we can discuss system replacement options or aftermarket motor specifications that meet the original torque and RPM requirements.
After a Schwintek motor replacement, the control board loses its stored travel limit positions for the slide room. The new motor must go through a calibration sequence: the slide is commanded to fully retract until the control board detects the motor stall that indicates the fully-in position, then fully deployed until the fully-out stall is detected. The board stores these positions and uses them to time out the slide travel in future cycles. Skipping calibration causes the slide to either under-travel (leaving a gap) or over-travel (damaging the stops). Our technicians complete calibration as standard procedure after every motor replacement.
Yes. Broward County's humidity regularly exceeds 80% and stays elevated overnight even in winter. Stored RVs that are not climate-controlled accumulate condensation inside the slide room walls where the Schwintek motor assemblies sit. Over time this moisture corrodes the motor brush assembly and creates carbon tracking on the commutator, reducing motor efficiency and eventually causing premature failure. RVs stored long-term in Broward County benefit from desiccant packets placed near the motor access panels and occasional battery-powered run cycles to keep components moving.
Serving Fort Lauderdale and All of Broward County
When your RV needs slide-out repair in Fort Lauderdale or anywhere in Broward County, our certified mobile team comes directly to your location - no tow truck required, no dealership wait. We dispatch to all Broward cities including Hollywood, Pembroke Pines, Coral Springs, Davie, Deerfield Beach, Pompano Beach, Sunrise, Miramar, Hallandale Beach, Plantation, Lauderhill, and Weston. Most calls receive a same-day or next-morning appointment.
South Florida's climate creates specific challenges for RV systems. Year-round temperatures averaging 77°F, with summer highs in the 90s and humidity regularly topping 80%, put RV components under constant thermal stress. Systems that function fine in cooler climates often show accelerated wear here. Our technicians are trained specifically on Florida climate impacts - from salt air corrosion affecting coastal Broward rigs to the effect of standing water after summer rainstorms on rubber seals and underbelly components.
We regularly service RVs at Broward County's most popular campgrounds: T.Y. Park (Topeekeegee Yugnee Park) in Hollywood, Easterlin Park in Oakland Park, CB Smith Park in Pembroke Pines, Quiet Waters Park in Deerfield Beach, and Tradewind Park in Coconut Creek. Give us your campsite number when you call and we'll come directly to your rig - no need to unhook or move your trailer.
Our team carries common replacement parts for all major RV brands including Winnebago, Forest River, Thor, Jayco, Keystone, Grand Design, Coachmen, Airstream, Tiffin, and Newmar. For less common components, we source parts same-day from Broward's RV supply distributors, keeping most repairs to a single visit. We provide written estimates before any work begins - no surprises on your final bill.
